MOZA RACING R5 Racing Simulator Bundle for PC / R5 Base + ES Wheel + SR-P Lite 2 Pedals

PENTING . IMPORTANT . 注意

KEPADA PELANGGAN YANG DIHORMATI,

SEBELUM MEMBUKA BUNGKUSAN SILA BUAT RAKAMAN VIDEO

BAGI TUJUAN TUNTUTAN KEROSAKAN DAN KEHILANGAN

SEBARANG TUNTUTAN TANPA RAKAMAN TIDAK AKAN DILAYAN.

SEGALA KERJASAMA AMATLAH DIHARGAI

DEAR VALUED CUSTOMER,

BEFORE UNBOXING THE PACKAGE PLEASE MAKE A

VIDEO RECORDING FOR FAULTY AND DAMAGE CLAIM PURPOSES

尊贵的顾客，请在打开包裹之前录制一段视频，

以确保产品损坏的情况有证据。未附带录制视频的索赔将无法受理。

谢谢您的合作

SPECIFICATION

***********************************************

DD R5

Platform

PC

FFB Drive System

Direct Drive

Max Steering Angle

Infinite Rotation

Housing Material

Aviation Grade Aluminum Alloy

Color

Black

Peak Torque

5.5Nm

USB Refresh Rate

1000Hz

Input Voltage

110V~220V AC —>12V DC

Encoder Resolution

15 bits

App Functions

Supported

Quick Release

Supported

Interface

Power, Data, Display, Pedals, Wheel Input

Accessories

User manual, Warranty card, Power supply, USB cable, Toolkit

Mounting Method

4 holes on the bottom

Desktop Mounting Clip

Standard

Online Firmware Upgrade

Supported

Emergency Stop Switch

Optional

Firmware Upgrade

Applicable

***********************************************

ES Steering Wheel

Wheel Material

Microfiber Leather

Frame and Front Plate Material

Aluminum Alloy

Dial Material

Aluminum Alloy

Size

11 inches

Buttons

22

LED Lamp Beads

10

Intelligent Telemetry

Supported

Configurable LEDS (MOZA Pit House)

Supported

Disassembly method

Quick Release System

***********************************************

SR-P Lite Pedals

Material

High-strength Steel

Plate Material

High-strength Steel

Color

Black

Pedal Sensor Type

Hall Sensor

Pedal Spacing

Adjustable

Pedal Plate Height

Adjustable

Pedal Input Adjustment

Supported

Pedal Input Reversal

Supported

Pedal Output Curve Adjustment

Supported

Anti-Slip Pad

Included

***********************************************

WHAT'S INBOX

● R5 Wheel Base x1

● ES Steering Wheel x1

● SR-P Lite Pedals (No Clutch) x1

● R5 Table Clamp

● 15 Degree Desktop Mounting Clip

● Power Supply

● Power Cord - AC cable (1.5m) & DC cable (1.8m)

● USB Cable (1.8m)

● M4*10 Socket Screws x12

● M6*20 Socket Head Screws x2

● M8 Nuts x3

● M6x12 Socket Head Screws x4

● Pedal Fixed Rubber Columns x2

● 2.5mm Hexagonal Wrench x1

● 7mm Open End Wrench x1

● 5mm Hexagonal Wrench x1

● Type A to Type B USB Cable x1 (1.8m)

● M8*12 Hexagonal Screws x3

**(2 Years Warranty for Wheelbase, 1 Year Warranty for Steering Wheel & Pedal)

*Change Of Mind/I Do Not Want The Product Anymore/Return Policy Does NOT Apply For Order(s) & Product(s) Which Has Been Used, Unboxed, Unsealed, Tampered, Not Returned Along Full Documentation/Tax Invoice & Original Retail Box With Shipping Packing

*For Warranty Purposes, Please Refer Our Official Website T&C
