PHANTEKS P200A High Airflow mini-ITX PC Case / Tempered Glass / DRGB / Closed Window

Product Description

The Eclipse P200A is a high airflow mini-ITX chassis featuring the Ultra-fine Performance Mesh to bring the highest cooling performance.

Features:

The open interior offers plenty of space for standard ATX power supplies, triple slot Graphics Cards and plenty of 240/280 radiator options in the front and side of the chassis.

The Eclipse P200A makes building a powerful yet compact ITX system a breeze.

P200A Performance

PH-EC200AC_BK01

Specifications

Case Dimension (WxHxD) 205 mm x 365 mm x 400 mm / 8.1 in x 14.4 in x 15.7 in

Form Factor Mini-ITX Tower

Materials Steel Chassis

Motherboard Support Mini-ITX, mini-DTX

Front IO 2x USB 3.0 Microphone/Headphone, Reset Button, Power Button

Connectors Power Switch, Reset Switch, HD-audio, Power-LED, USB 3.0

PCI Slots 3

Vertical GPU ready Yes, 3-slots (PH-CBRS_FLTS Phanteks Riser Cable required sold separately)

Internal 3.5” bay 4 (Stackable 3.5” Bracket sold separately/not included)

Internal 2.5” bay 4 (4x included)

Total Fan Mounts 7 x 120 mm / 2 x 140 mm + 5 x 120 mm

Front Fan 2 x 120 mm / 2 x 140 mm (2 x 120 mm Black PWM included)

Side Fan 2 x 120 mm

Rear Fan 1 x 120 mm

Bottom Fan 2 x 120 mm

Dust Filters base

Front Radiator Up to 240/280 mm

Side Radiator Up to 240 mm

Rear Radiator 120 mm

Front Radiator Clearance 140 x 325 mm

Side Radiator Clearance 120 x 279 mm

GPU Length 355mm/13.98 in

GPU Thickness 3-slot, 65 mm

CPU Cooler Height 165 mm / 6.5 in

CPU Cooler Height with Vertical GPU 72mm or 92mm depending on Vertical PCI slot position

PSU Length 205 mm (190 mm recommended)

Package Dimension 415 x 285 x 485 mm

----------------------------------------------------------------------------------------------------------------------------------

P200A DRGB

PH-EC200ATG_DBK01

Specifications

Case Dimension (WxHxD) 205 mm x 365 mm x 400 mm / 8.1 in x 14.4 in x 15.7 in

Form Factor Mini-ITX Tower

Materials Steel Chassis, Tempered Glass Window

Motherboard Support Mini-ITX, mini-DTX

Front IO USB-C GEN 2 (10Gbps), 2x USB 3.0, Microphone/Headphone, LED Mode Button, LED Colour Button, Power Button

Connectors Power Switch, D-RGB Expansion, D-RGB Third Party, D-RGB MB Adapter, HD-audio, USB 3.0, USB 3.2 GEN2 Type-E, SATA

PCI Slots 3

Vertical GPU ready Yes, 3-slots (PH-CBRS_FLTS Phanteks Riser Cable required sold separately)

Internal 3.5” bay 4 (Stackable 3.5” Bracket sold separately/not included)

Internal 2.5” bay 4 (4x included)

Total Fan Mounts 7 x 120 mm / 2 x 140 mm + 5 x 120 mm

Front Fan 2 x 120 mm / 2 x140 mm (2 x 120 mm D-RGB PWM included)

Side Fan 2 x 120 mm

Rear Fan 1 x 120 mm

Bottom Fan 2 x 120 mm

Dust Filters base

Front Radiator Up to 240/280 mm

Side Radiator Up to 240 mm

Rear Radiator 120 mm

Front Radiator Clearance 140 x 325 mm

Side Radiator Clearance 120 x 279 mm

GPU Length 355mm/13.98 in

GPU Thickness 3-slot, 65 mm

CPU Cooler Height 165 mm / 6.5 in

CPU Cooler Height with Vertical GPU 72mm or 92mm depending on Vertical PCI slot position

PSU Length 205 mm (190 mm recommended)

Package Dimen
