Seasonic PRIME TX-850 / TX-1000 / TX-1300 ATX 3.0 / 80+ TITANIUM FULL MODULAR ATX POWER SUPPLY PSU

The Seasonic PRIME TX ATX 3.0 Series is built on top of all the great features of PRIME TX platform with added ATX 3.0 and PCIe 5.0 compatibility. Currently the 1600 W and 1300 W units are equipped with native 12VHPWR connectors, Digital Fan Control, and 105°C-rated Japanese electrolytic capacitors guarantee unwavering power delivery and long-term durability. All these qualities make these power supplies perfect to welcome the newest high power graphic cards and processors on the market.

Specifications

80PLUS® Titanium

Cybenetics Efficiency Level Titanium

Cybenetics Noise Level Lambda A

Form Factor ATX/EPS

Dimensions 210 × 150 × 86 mm

Fan Information Fan Size 135 mm

Fan Control Digital Hybrid Fan Control

Fan Bearing Fluid Dynamic Bearing

Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH

Cable Information Modularity Fully Modular

Cable type Individual Black Cables with Braided Pattern

SSR-850TR

850W Specifications

Size ATX

Edition PRIME ULTRA TITANIUM 850

Wattage 850 W

80 PLUS Certification 80 PLUS Titanium

Max. Efficiency (at 230Vac) 96 %

Cooling Fan

Fans 1 x 135mm

Internal +12V Rails Single Rail

Rail 1 +12V 70 A

Rail 2 +12V N/A

Rail 3 +12V N/A

Rail 4 +12V N/A

Rail 5 +12V N/A

Rail 6 +12V N/A

Max. Combined Output +12V 70 A

Modular Yes

Modularity Full Modular

SLI/CrossFire Yes

EPS 12V Yes

Motherboard Connector 20+4-pin

Connectors

2 x 4+4-pin CPU +12V (EPS)

1 x 4-pin FDD Power

5 x 4-pin Molex

6 x 6+2-pin PCIe

10 x SATA

Dimensions 150 x 86 x 170 mm (WxHxD)

Package Type Retail

SSR-1000TR

1000W Specifications

Size ATX

Edition PRIME ULTRA TITANIUM 1000

Wattage 1000 W

80 PLUS Certification 80 PLUS Titanium

Max. Efficiency (at 230Vac) 96 %

Cooling Fan

Fans 1 x 135mm

Internal +12V Rails Single Rail

Rail 1 +12V 83 A

Rail 2 +12V N/A

Rail 3 +12V N/A

Rail 4 +12V N/A

Rail 5 +12V N/A

Rail 6 +12V N/A

Max. Combined Output +12V 83 A

Modular Yes

Modularity Full Modular

SLI/CrossFire Yes

EPS 12V Yes

Motherboard Connector 20+4-pin

Connectors

2 x 4+4-pin CPU +12V (EPS)

1 x 4-pin FDD Power

5 x 4-pin Molex

8 x 6+2-pin PCIe

14 x SATA

Dimensions 150 x 86 x 170 (WxHxD)

Package Type Retail
