General Specifications
Platform
Desktop
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 7 8000 G-Series Desktop Processors with Radeon™ Graphics
AMD PRO Technologies
No
Consumer Use
Yes
Regional Availability
Global
Former Codename
"Phoenix"
Architecture
"Zen 4"
# of CPU Cores
8
Multithreading (SMT)
Yes
# of Threads
16
Max. Boost Clock
Up to 5.1GHz
Base Clock
4.2GHz
L2 Cache
8MB
L3 Cache
16MB
Default TDP
65W
AMD Configurable TDP (cTDP)
45-65W
Processor Technology for CPU Cores
TSMC 4nm FinFET
CPU Compute Die (CCD) Size
178mm²
Package Die Count
1
Unlocked for Overclocking
Yes
AMD EXPO™ Memory Overclocking Technology
Yes
Precision Boost Overdrive
Yes
Curve Optimizer Voltage Offsets
Yes
AMD Ryzen™ Master Support
Yes
CPU Socket
AM5
CPU Boost Technology
Precision Boost 2
Instruction Set
x86-64
Supported Extensions
AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax)
95°C
*OS Support
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
Native USB 4 (40Gbps) Ports
2
Native USB 3.2 Gen 2 (10Gbps) Ports
2
Native USB 2.0 (480Mbps) Ports
1
PCI Express® Version
PCIe® 4.0
Native PCIe® Lanes (Total/Usable)
20 / 16
NVMe Support
Boot, RAID0, RAID1
System Memory Type
DDR5
Memory Channels
2
Max. Memory
256GB
System Memory Subtype
UDIMM
Max Memory Speed
2x1R
DDR5-5200
2x2R
DDR5-5200
4X1R
DDR5-3600
4x2R
DDR5-3600
Graphics Capabilities
Integrated Graphics
Yes
Graphics Model
AMD Radeon™ 780M
Graphics Core Count
12
Graphics Frequency
2900 MHz
DirectX® Version
12
DisplayPort™ Version
2.1
DisplayPort Extensions
HDR Metadata
Adaptive-Sync
UHBR10
DisplayPort Max Refresh Rates (SDR)
7680x4320 @ 60Hz
3840x2160 @ 240Hz
3440x1440 @ 360Hz
2560x1440 @ 480Hz
1920x1080 @ 600Hz
DisplayPort Max Refresh Rates (HDR)
7680x4320 @ 60Hz
3840x2160 @ 240Hz
3440x1440 @ 360Hz
2560x1440 @ 480Hz
1920x1080 @ 600Hz
HDMI® Version
2.1
HDCP Version Supported
2.3
USB Type-C® DisplayPort™ Alternate Mode
Yes
Multi-Monitor Support
Yes
Max Displays
4
AMD Ryzen™ AI Available
Performance
Up to 16 TOPS
