Chipset
AMD B850
Processor
Supports AMD Ryzen 7000/8000/9000 series processors that fit the AMD AM5 slot of the motherboard
(* Please visit www.colorful.cn for the latest memory compatibility list)
Memory
2 DDR5 memory sockets are provided, which can support up to 128 GB of memory (a single socket can support up to 64 GB of memory)
Ryzen™ 9000 Series: Supports up to DDR5-8400+ MT/s (OC)
Ryzen™ 8000 Series: Supports up to DDR5-10200+ MT/s (OC)
Ryzen™ 7000 Series: Supports up to DDR5-8000+ MT/s (OC)
Supports Extreme Memory Profile (XMP) memory technology
Supports Extended Profiles for Overclocking (EXPO) memory technology
Supports dual-channel memory technology
（ *The motherboard's memory frequency limit is determined by the CPU's memory controller performance and the characteristics of the memory chips themselves）
(*Please visit Colorful's official website www.colorful.cn for the latest memory compatibility list)
SATA Ports
2 M.2 slots and 2 SATA 6Gb/s hard disk interfaces, and supports creating RAID 0, RAID 1 RAID with SATA or M.2 NVMe hard disk devices
- M.2_1 slot: supports 2280 M.2 SSD (PCIe 5.0 x4, CPU channel)
- M.2_2 slot: supports 2280 M.2 SSD (PCIe 5.0 x4, CPU channel)
(*Single-sided SSDs are recommended for the rear drive bay)
(*PCIe 5.0 support depends on the CPU paired with the motherboard)
Board I/O
Rear I/O :
-4×USB 2.0 interfaces
-2×USB 3.2 Gen 1 5Gbps Type-A interfaces
-1×USB 3.2 Gen 2 10Gbps Type-A interface
-1×USB 3.2 Gen 2x2 20Gbps Type-C interface
-1×DP 1.2 interface, supporting up to 4K 60Hz resolution
-1×HDMI 2.0 interface, Supports up to 4K 60Hz resolution
-1×5G network interface
-2×WiFi 7 antenna interfaces
-3×Audio interfaces (audio input/audio output/microphone)
-1×BIOS update button
-1×CMOS clearing key
On board:
-1×USB 2.0 pin expandable 2 USB 2.0 Type-A interfaces
-1×USB 3.2 Gen 1 pin expandable 2 USB 3.2 Gen 1 5Gbps Type-A interfaces
-1×USB 3.2 Gen 2 Type-C slot expandable 1 USB 3.2 Gen 2 10Gbps Type-C interface
-1×CPU fan pin
-1×System fan pin
-1×Water cooling pump pin
-2×5V 3-pin ARGB pins
-1×Front audio pin
-1×Front panel pin
-1×Speaker pin
Expansion Slots
1×PCIe 5.0 x16 slot
BIOS
256M UEFI, support multiple languages
Power Management
Support S3/S4 wake-up, network S5 wake-up, support USB wake-up, support timing boot, call boot
Hardware Monitor
CPU fan speed is controllable, system fan speed is controllable, CPU temperature monitoring, system temperature monitoring, and each group of voltage monitoring
LAN
RTL8126-CG 5Gbit network card, MT7925 WiFi 7 wireless network card, Bluetooth 5.4
- Wi-Fi functionality may vary depending on the operating system.
- For Windows 11, Wi-Fi 7 requires version 24H2 or later for full functionality. Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E.
Audio
Realtek ALC897 high fidelity decoding chip, Support up to 7.1 channels
Configuration
ITX
170 x 170
