● Flexible compatibility
● ATX 3.0 support & a 90-degree 12VHPWR cable
● 80 PLUS Gold certified
● Fully modular cabling
● High-quality Japanese capacitors
● 10-year Warranty
ATX Version
ATX 3.0, SFX 12V Ver. 3.42
PFC
Active PFC
Input Voltage
100-240V
Input Current
12-6A
Input Frequency
50-60Hz
Dimensions (L x W x H)
100 x 125 x 63.5 mm
Fan Size
92mm
Fan Bearing
FDB
Efficiency
90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ETA Rating
Gold
LAMBDA Rating
Standard+
ErP 2014 Lot 3
Yes
Operating Temperature
0-50°C
Power Good Signal
100 - 500 ms
Hold Up Time
16ms
MTBF
>100,000 Hours
Protections
OVP, OPP, SCP, OCP, UVP, OTP, Surge and Inrush Protection
Regulatory
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA
ATX 24 Pin Connectors
1
EPS 4+4 Pin Connectors
1
EPS 8 Pin Connector
1
SATA Connectors
2
Peripheral 4 Pin Connectors
1
PCI-e 6+2 Pin Connectors
2
12VHPWR Connector
1
Series
V SFX Series
80 Plus
Gold
Modular
Fully Modular
Wattage
Above 750W
