DeepCool CH160 / CH160 Plus High Airflow Ultra Portable Case ITX & mATX With Handle

CH160 - Technical Spec

Product Dimensions

336×200×283.5mm(L×W×H)

Net Weight

3.3Kg

Materials

ABS+SPCC+Tempered Glass

Motherboard Support

Mini-ITX

Front I/O Ports

USB3.0×2、Audio×1、Gen2 Type-C×1

3.5" Drive Bays

1（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）

2.5" Drive Bays

1（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）

Expansion Slots

3 Slots

Pre-Installed Fans

None

Fan Support

Front: 1×120 mm（2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three）

Top: 2×120mm

Rear: 1×120mm

Radiator Support

None

CPU Cooler Height Limit

172mm

GPU Size Limit

Length: SFX/SFX-L: 305mm / ATX: 230mm

Height: 138mm

Width: 65mm (3 Slots)

Power Supply Type

ATX PS2（maximum length: 140mm）/ SFX / SFX-L

***********************************************************************************************************************

CH160 PLUS - Technical Spec

Product Dimensions 375mm*195mm*323.5mm(L×W×H)

Net Weight 4.2Kg

Materials ABS+SPCC+Tempered Glass

Motherboard Support Mini-ITX / Micro-ATX

Front I/O Ports USB3.0×2、Gen2 Type-C x1、Audio/Mic×1

3.5" Drive Bays 1

2.5" Drive Bays 1+1

Expansion Slots 4Slots

Pre-Installed Fans None

Fan Support

Front:1×120mm/1×140mm（With SFX PSU）

Top:2×120mm

Rear: 1×120mm

Radiator Support

Front: NA

Top:120/240mm

Bottom: NA

Rear:120mm

CPU Cooler Height Limit 164mm

GPU Length Limit 342mm

Power Supply Type ATX PS2（maximum length: 140mm)/SFX/SFX-L
