GIGABYTE GS24F14 Gaming Monitor 23.8'' / FHD / IPS / 1ms / 144Hz / Flicker-Free / Low Blue Light & Adaptive-Sync

PENTING . IMPORTANT . 注意

KEPADA PELANGGAN YANG DIHORMATI,

SEBELUM MEMBUKA BUNGKUSAN SILA BUAT RAKAMAN VIDEO

BAGI TUJUAN TUNTUTAN KEROSAKAN DAN KEHILANGAN

SEBARANG TUNTUTAN TANPA RAKAMAN TIDAK AKAN DILAYAN.

SEGALA KERJASAMA AMATLAH DIHARGAI

DEAR VALUED CUSTOMER,

BEFORE UNBOXING THE PACKAGE PLEASE MAKE A

VIDEO RECORDING FOR FAULTY AND DAMAGE CLAIM PURPOSES

尊贵的顾客，请在打开包裹之前录制一段视频，

以确保产品损坏的情况有证据。未附带录制视频的索赔将无法受理。

谢谢您的合作

Panel Size (diagonal)

23.8" IPS

Display Viewing Area (HxV)

527.04 x 296.46 (mm)

Panel Backlight/ Type

Edge

Display Surface(non-glare/ glare)

Non-glare

Color Saturation

104% sRGB, 81% DCI-P3

True Resolution

1920 x 1080(FHD)

Pixel Pitch

0.2745 x 0.2745

Brightness

300 cd/m2 (TYP)

Contrast Ratio

1500:1

Viewing Angle

178°(H)/178°(V)

Display Colors

6bit + Hi-FRC

Response Time

1ms MPRT

Refresh Rate

144Hz

HDR

NA

Flicker-free

Yes

Connectivity

1 x HDMI 1.4

1 x Displayport 1.2

Power Type

Adaptor

Power Consumption

11W

Power Saving Mode

<0.5W

Power Off Mode

<0.3W

Voltage

AC 100-240V ~ 50/60Hz

Tilt(angle)

-5°~+20°

Swivel(angle)

N/A

Pivot(angle/direction)

N/A

Height Adjustment (mm)

N/A

VESA Wall Mounting(mm)

75 x 75 mm

Kensington lock

Yes

Phys. Dimension with Stand(WxHxD)

537.7 x 414.5 x 152 mm

Phys. Dimension w/o stand (WxHxD)

537.7 x 317 x 37.5 mm

Box Dimension (WxHxD)

653 x 436 x 133 mm

Net Weight with stand (Esti.)

3.14 kg

Net Weight without stand (Esti.)

2.63 kg

Gross Weight (Esti.)

4.0 kg

Accessories

Power cable/HDMI cable/QSG/Warranty card

Note

*To enable OSD Sidekick, it requires connection between PC and monitor with USB (A-Male to B-Male) cable.

**The test condition follows CEC standards.
