GIGABYTE M27UP 27“ GAMING MONITOR Normal / Ice 27” SSIPS UHD / 1MS / 160HZ / FREESYNC / SPEAKER / HD MI + DP

PENTING . IMPORTANT . 注意

KEPADA PELANGGAN YANG DIHORMATI,

SEBELUM MEMBUKA BUNGKUSAN SILA BUAT RAKAMAN VIDEO

BAGI TUJUAN TUNTUTAN KEROSAKAN DAN KEHILANGAN

SEBARANG TUNTUTAN TANPA RAKAMAN TIDAK AKAN DILAYAN.

SEGALA KERJASAMA AMATLAH DIHARGAI

DEAR VALUED CUSTOMER,

BEFORE UNBOXING THE PACKAGE PLEASE MAKE A

VIDEO RECORDING FOR FAULTY AND DAMAGE CLAIM PURPOSES

尊贵的顾客，请在打开包裹之前录制一段视频，

以确保产品损坏的情况有证据。未附带录制视频的索赔将无法受理。

谢谢您的合作

Model : M27UP Gaming Monitor

Panel Size (diagonal)

27" SS IPS

Display Viewing Area

596.16 x 335.34 (mm)

Panel Backlight/ Type

Edge

Display Surface(non-glare/ glare)

Non-glare

Color Saturation

95% DCI-P3/ 125% sRGB

True Resolution

3840 x 2160 (UHD)

Pixel Pitch

0.1554 (H) x 0.1554 (V)

Brightness

350 cd/m2 (TYP)

Contrast Ratio

1000:1

Viewing Angle

178°(H)/178°(V)

Display Colors

1.07B

Response Time

1ms GTG

Refresh Rate

160Hz

HDR

VESA Display HDR400

Flicker-free

Yes

HBR3

Yes

Connectivity

2 x HDMI 2.1

1 x Display port 1.4 (DSC)

3 x USB 3.2 Gen 1 Downstream ports

1 x USB 3.2 Gen 1 Upstream port

1 x USB Type-C (Alternate Mode; Upstream port; Power Delivery up to 18W)

1 x Earphone Jack

Speaker

5W x2

Power Type

Power Board Build-in

Power Consumption

27.6W ***

Power Saving Mode

<0.5W

Power Off Mode

<0.3W

Voltage

AC 100-240V ~ 50/60Hz

Tilt(angle)

-5°~+20°

Swivel(angle)

±15°

Pivot(angle/direction)

-0°~+90° (clockwise)

Height Adjustment (mm)

130 mm

VESA Wall Mounting(mm)

100*100 mm

Kensington lock

Yes

Phys. Dimension with Stand

615.67*517.65*193.63 mm

Phys. Dimension w/o stand

615.67*371.15*60.3 mm

Box Dimension

939*490*167 mm

Net Weight with stand

6.48 kg

Net Weight without stand

4.56 kg

Gross Weight

9.9 kg

Accessories

Power cable/HDMI 2.1 cable/DP cable/USB cable/QSG/Warranty card
