CPU Specifications
Total Cores
18
# of Performance-cores
6
# of Efficient-cores
12
# of Low Power Efficient-cores
0
Total Threads
18
Max Turbo Frequency
5.3 GHz
Performance-core Max Turbo Frequency
5.3 GHz
Efficient-core Max Turbo Frequency
4.6 GHz
Performance-core Base Frequency
4.2 GHz
Efficient-core Base Frequency
3.3 GHz
Cache
30 MB Intel® Smart Cache
Total L2 Cache
30 MB
Processor Base Power
125 W
Maximum Turbo Power
159 W
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
AI Software Frameworks Supported by CPU
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography
TSMC N3B
**********************************************
Memory Specifications
Max Memory Size (dependent on memory type)
256 GB
Memory Types
Up To DDR5 7200 MT/s
Max # of Memory Channels
2
ECC Memory Supported ‡
Yes
**********************************************
GPU Specifications (250K PLUS)
GPU Name‡
Intel® Graphics
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.9 GHz
GPU Peak TOPS (Int8)
8
Graphics Output
eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
Xe-cores
4
Max Resolution (HDMI)‡
4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)
7680 x 4320 @ 60Hz (HDMI 2.1 FRL)
Max Resolution (DP)‡
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)‡
3840 x 2400 @ 120Hz
DirectX* Support
12
OpenGL* Support
4.5
OpenCL* Support
3
H.264 Hardware Encode/Decode
Yes
H.265 (HEVC) Hardware Encode/Decode
Yes
AV1 Encode/Decode
Yes
Intel® Quick Sync Video
Yes
# of Displays Supported ‡
4
Device ID
0x7D67
Intel® Deep Learning Boost (Intel® DL Boost) on GPU
Yes
AI Software Frameworks Supported by GPU
OpenVINO™, WindowsML, DirectML, ONNX RT, WebGPU
**********************************************
NPU Specifications
NPU Name‡
Intel® AI Boost
NPU Peak TOPS (Int8)
13
Sparsity Support
Yes
Windows Studio Effects Support
Yes
AI Software Frameworks Supported by NPU
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
**********************************************
Expansion Options
Direct Media Interface (DMI) Revision
4
Max # of DMI Lanes
8
Intel® Thunderbolt™ 4
Yes
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations ‡
Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
Max # of PCI Express Lanes
24
**********************************************
Package Specifications
Sockets Supported
FCLGA1851
Thermal Solution Specification
PCG 2020A
