Form factor M.2 2280
Interface PCIe 4.0 x4 NVMe
Capacities1 240GB, 480GB, 960GB
NAND 3D TLC
Sequential read/write 240GB – 4500/400 MBs
480GB – 7000/800 MBs
960GB – 7000/1300 MBs
Steady-state 4k read/write2 240GB – 260000/18000 IOPS
480GB – 530000/32000 IOPS
960GB – 540000/47000 IOPS
Total bytes written (TBW)3 240GB – 175 TBW
480GB – 350 TBW
960GB – 700 TBW
Latency read (avg) 240GB-960GB: 70µs
Latency write (avg) 240GB – 53µs
480GB – 29µs
960GB – 20µs
Power loss protection (power caps) Yes
Enterprise SMART tools Reliability tracking, usage statistics, SSD life remaining, wear levelling, temperature
Endurance 240GB — (0.4 DWPD/5yrs)4
480GB — (0.4 DWPD/5yrs)4
960GB — (0.4 DWPD/5yrs)4
Power consumption 240GB: Average read: 2.97W Average write: 4.02W Max read: 3.01W Max write: 4.09W
480GB: Average read: 3.22W Average write: 5.60W Max read: 3.29W Max write: 5.77W
960GB: Average read: 3.26W Average write: 7.36W Max read: 3.36W Max write: 7.80W
Storage temperature -40°C ~ 85℃
Operating temperature 0℃ ~ 70℃
Dimensions Heatsink:
80mm x 22mm x 8.3mm
Non-heatsink
80mm x 22mm x 3.5mm
Weight 240GB – 9g
480GB – 10g
960GB – 11g
Vibration non-operating 20G peak (10-2,000Hz)
MTBF 2 million hours
Warranty/support5 Limited five-year warranty with free technical support
