Form factor 2.5 inch
Interface SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s)
Capacities1 480GB, 960GB, 1.92TB, 3.84TB, 7.68TB
NAND 3D TLC
DRAM Cache Yes
Sequential read/write 480GB – 560MBs/470MBs
960GB – 560MBs/530MBs
1.92TB – 560MBs/530MBs
3.84TB – 560MBs/530MBs
7.68TB – 560MBs/530MBs
Steady-state 4k random read/write 480GB – 94,000/41,000 IOPS
960GB – 94,000/65,000 IOPS
1.92TB – 94,000/78,000 IOPS
3.84TB – 94,000/59,000 IOPS
7.68TB – 94,000/34,000 IOPS
Quality of service (latency)2,3,4(99.999) Read/Write
480GB – 500/130 uSec
960GB - 200/400 uSec
1.92TB – 450/210 uSec
3.84TB - 410/500 uSec
7.68TB – 200/100 uSec
Typical latency - read/write <130 µs / <70 us2,3,4
Hot-plug capable Static and dynamic wear levelling
Enterprise SMART tools Reliability tracking, usage statistics, life remaining, wear levelling, temperature
Hardware-based power loss protection Yes
Endurance (TBW) 5 480GB – 876TBW, 1 DWPD (5 years), 1.66 DWPD (3 years)
960GB – 1752TBW, 1 DWPD (5 years), 1.66 DWPD (3 years)
1.92TB – 3504TBW, 1 DWPD (5 years), 1.66 DWPD (3 years)
3.84TB – 7008TBW, 1 DWPD (5 years), 1.66 DWPD (3 years)
7.68TB – 14016TBW, 1 DWPD (5 years), 1.66 DWPD (3 years)
Power consumption Idle: 1.30W
Average: 1.45W
Max read: 1.6W
Max write: 3.6W
Storage temperature -40℃ ~ 85℃
Operating temperature 0℃ ~ 70℃
Dimensions 69.9mm x 100mm x 7mm
Weight 92.34g
Vibration operating 2.17G Peak (7–800Hz)
Vibration non-operating 20G peak (10–2000Hz)
MTBF 2 million hours
UBER ≤10 -17
Warranty/support Limited 5-year warranty with free technical support6
