PCIe 4.0 NVMe high-performance
Compact M.2 2280 form factor
Low profile graphene aluminum heat spreader
Specifications
Form Factor M.2 2280
Interface PCIe 4.0 NVMe
Capacities 512GB, 1024GB, 2048GB
Controller Phison E18
NAND 3D TLC
Sequential Read/Write
512GB – 7,000/3,900MB/s
1024GB – 7,000/6,000MB/s
2048GB – 7,000/7,000MB/s
Random 4K Read/Write1
512GB – up to 450,000/900,000 IOPS
1024GB – up to 900,000/1,000,000 IOPS
2048GB – up to 1,000,000/1,000,000 IOPS
Total Bytes Written (TBW)3
512GB – 400TBW
1024GB – 800TBW
2048GB – 1.6PBW
Power Consumption
512GB – 5mW Idle / 0.34W Avg / 2.7W (MAX) Read / 4.1W (MAX) Write
1024GB – 5mW Idle / 0.33W Avg / 2.8W (MAX) Read / 6.3W (MAX) Write
2048GB – 5mW Idle / 0.36W Avg / 2.8W (MAX) Read / 9.9W (MAX) Write
Storage Temperature
-40°C~85°C
Operating Temperature
0°C~70°C
Dimensions
80mm x 22mm x 2.21mm (512GB-1024GB)
80mm x 22mm x 3.5mm (2048GB)
Weight
512GB-1024GB – 7g
2048GB– 9.7g
Vibration Operating
2.17G Peak (7-800Hz)
Vibration Non-operating
20G Peak (20-1000Hz)
MTBF
1,800,000 hours
Warranty/support4
Limited 5-year warranty with free technical support
This SSD is designed for use in desktop and notebook computer workloads and is not intended for Server environments.
1. Based on “out-of-box performance” using a PCIe 4.0 motherboard. Speed may vary due to host hardware, software and usage.
2. Some of the listed capacity on a Flash storage device is used for formatting and other functions and thus is not available for data storage. As such, the actual available capacity for data storage is less than what is listed on the products. For more information, go to Kingston's Flash Memory Guide.
3. Total Bytes Written (TBW) is derived from the JEDEC Client Workload (JESD219A).
4. Limited warranty based on 5 years or “Percentage Used” which can be found using the Kingston SSD Manager (kingston.com/ssdmanager). For NVMe SSDs, a new unused product will show a Percentage Used value of 0, whereas a product that reaches its warranty limit will show a Percentage Used value of greater than or equal to one hundred (100). See kingston.com/wa for details.
