Display Features
DisplayPort 2.1b – 8K and Beyond at High Refresh Rates
With DisplayPort 2.1b, professionals can achieve unparalleled visual clarity and performance, driving high-resolution displays at up to 8K at 240Hz and 16K at 60Hz. Increased bandwidth enables seamless multi-monitor setups, ideal for multitasking and collaboration, while HDR and higher color depth support ensures superior color accuracy for precision work, such as video editing, 3D design, and live broadcasting. Support up to four 4K displays @ 165Hz per card or up to two 8K displays @ 100Hz with DSC using DP or HDMI. Highest link rates require a DP80LL certified cable.
NVIDIA RTX™ Desktop Manager
Gain unprecedented end-user control of the desktop experience for increased productivity in a single large display or multi-display environments, especially in the current age of large, widescreen displays.
NVIDIA RTX PRO Sync1
Synchronize the display and image output of up to 32 displays2 from 8 GPUs (connected through two Sync boards) in a single system, reducing the number of machines needed to create an advanced video visualization environment. Or, expand beyond a single machine and synchronize hundreds of displays across multiple systems for large deployments using Sync. Experience the added benefit of Variable Refresh Rate (up to 1000Hz) when you pair an RTX PRO Blackwell GPU (4000 class and above) to the RTX PRO Sync add in card. VRR enables varying refresh rates on synchronized displays that help them adjust rapidly in areas of low latency.
NVIDIA Mosaic Technology
Transparently scale the desktop and applications across up to 4 GPUs and 16 displays from a single workstation while delivering full performance and image quality. This enables resolutions up to 16K x 16K in Windows, up to 32K x 32K in Linux. Mosaic can be combined with RTX PRO Sync to synchronize displays in this configuration.
Frame Lock Connector Latch
Each frame lock connector is designed with a self-locking retention mechanism to secure its connection with the frame lock cable to provide robust connectivity and maximum productivity.
Professional 3D Stereo Synchronization
Robust control of stereo effects through a dedicated connection to directly synchronize 3D stereo hardware to an NVIDIA RTX PRO graphics card.
| Architecture |
NVIDIA Blackwell Architecture |
| CUDA Parallel Processing Cores |
24,064 |
| NVIDIA Tensor Cores |
752 |
| NVIDIA RT Cores |
188 |
| Single-Precision Performance1
|
125 TFLOPS |
| AI Performance1
|
4000 AI TOPS2
|
| RT Core Performance1
|
380 TFLOPS |
| GPU Memory |
96 GB GDDR7 with ECC |
| Memory Interface |
512-bit |
| Memory Bandwidth |
1792 GB/s |
| Max Power Consumption |
600W |
| Multi-Instance GPU |
Up to 4x 24GB
Up to 2x 48GB
Up to 1x 96GB |
| Graphics Bus |
PCI Express 5.0 x16 |
| Display Connectors |
DP 2.1 (4) |
| Form Factor |
5.4” H x 12” L, XHFL Dual Slot |
| Product Weight |
1.950 kg |
| Thermal Solution |
Double Flow Through |
| NVIDIA® 3D Vision® and 3D Vision Pro |
Support via 3-pin mini DIN |
| Frame Lock |
Compatible (with NVIDIA RTX PRO Sync) |
| Power Connector |
1x PCIe CEM5 16-pin |
| NVENC | NVDEC | JPEG |
4x | 4x | 4x |
