Specifications
Capacities
1TB/2TB
Form Factor
M.2 2280
Interface
PCIe Gen4x4
Speed
1TB—Sequential Read up to 7000MB/s, Sequential Write Speed up to 6000MB/s, random read up to 800,000 IOPs, random write up to 600,000 IOPs1
2TB—Sequential Read up to 7000MB/s, Sequential Write Speed up to 6000MB/s, random read up to 800,000 IOPs, random write up to 600,000 IOPs1
Operating Temperature
0°C to 70°C (32°F to 158°F)
Storage Temperature
-40°C to 85°C (-40°F to 185°F)
Dimensions (L x W x H)
80 x 22 x 2.45 mm (3.15” x 0.87” x 0.10”)
Weight
6g / 0.013 lbs
Warranty
Five-year limited warranty
Shock-resistant
1500G, duration 0.5ms, Half Sine Wave2
Vibration-resistant
10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis(X,Y,Z)2
TBW
500GB:300TBW，1TB:600TBW，2TB:1200TBW
MTBF
1,500,000 Hours
