● 6”LCD at the bottom of the panel: 60Hz refresh rate, 720×1600 pixels resolution, and 500 nits brightness.
● M-ATX sized case with ATX compatibility
● Included 2 x 140mm PWM fans at the front, and 2 x 120mm PWM fans at the bottom
● Supports 360 radiator on the top and GPU up to 375mm long
● Motherboard tray position redesigned slightly lower into the PSU shroud with two bottom fans placed directly under the GPU for better cooling
● Well ventilated mesh panels on the front, top, and bottom, enhancing airflow
● Unique front PSU Installation
● GPU Anti-sag Bracket Included
SPECIFICATIONS
MODEL NAME
LAN207DX
COLOR
Black
DIMENSION
(D) 455.6mm x (W) 219mm x (H) 456mm
MATERIAL
Steel/ 4.0mm Tempered Glass
EXPANSION SLOTS
7
MOTHERBOARD SUPPORT
Standard ATX ( Width Max 244mm ) / Micro-ATX/Mini-ITX
PSU SUPPORT
(Under 160mm)
FAN SUPPORT
Front: 140mm x 2
Top: 120mm x 3 or 140mm x 2
Above PSU Shroud: 120mm x 2
Rear: 120mm x 1
RADIATOR SUPPORT
Top: 360/280/240mm
DRIVE SUPPORT
2x 3.5″ HDD or 2.5″ SSD
GPU LENGTH CLEARANCE
375mm (Max.)
CPU HEIGHT CLEARANCE
180mm (Max.)
I/O PORTS
USB 3.0 × 2
USB 3.2 TYPE-C × 1
Audio × 1
Power Button × 1
DUST FILTER
1 x Bottom
SCREEN
6 inch
SCREEN RESOLUTION
720×1600 pixels
SCREEN REFRESH RATE
RATE 60Hz
SCREEN BRIGHTNESS
500nits
