▶ Equipped with AMD Ryzen™ AI Max+ 395
▶ AI Performance · Up to 126 TOPS
▶ LPDDR5x-8000MT/s | Up To 128GB
▶ USB4 V2 & Dual 10GbE & WIFI 7
▶ PCIE x16 Expansion | Support 2U Rack
MS-S1 MAX Specification
CPU
AMD Ryzen™ AI Max+ 395
16 Cores, 32 Threads
Max Clock: 5.1 GHz
TDP
Performance Mode: 130W
Balanced Mode: 95W
Quiet Mode: 60W
GPU
Radeon 8060S Graphics (Internal)
GPU Cores: 40
GPU Clock: 2900 MHz
AI Engine Performance
AMD Ryzen™ AI
NPU Computing Power: Up to 50 TOPS
Total Computing Power: Up to 126 TOPS
RAM
LPDDR5x-256Bit
Max frequency support: 8000MHz
Max capacity support: 128GB
SSD
1× M.2 2280 NVMe SSD slot
(supports up to 8TB, PCIe 4.0 ×4)
1× M.2 2280 NVMe SSD slot
(supports up to 8TB, PCIe 4.0 ×1)
Heat Dissipation
6 Heat Pipes & Phase Change Material
Dual Turbine Fans
Max CPU Fan Speed: 3600 RPM
Wireless Connectivity
Wi-Fi 7 | Bluetooth® 5.4
Ethernet Controller
2× 10GbE LAN (RJ45)
Video Output
1× HDMI (up to 8K@60Hz/4K@120Hz)
2× USB4 (up to 8K@60Hz/4K@120Hz)
2× USB4 V2 (up to 8K@60Hz/4K@120Hz)
Audio Output
HDMI ×1
3.5mm Audio Combo Jack (TRRS) ×1
Audio Input
DMIC ×2
3.5mm Audio Combo Jack (TRRS) ×1
I/O Ports (Front)
2× USB4 (40Gbps, Alt DP 2.0, PD out 15W)
1× USB 3.2 Gen2 (10Gbps)
1× 3.5mm Audio Combo Jack (TRRS)
2× DMIC
I/O Ports (Rear)
1× 10GbE LAN (RJ45, Realtek RTL8127)
1× 10GbE LAN (RJ45, Realtek RTL8127)
2× USB 3.2 Gen2 (10Gbps)
2× USB 2.0
2× USB4 V2 (80Gbps, Alt DP2.0, PD out 15W)
1× HDMI 2.1 FRL (Up to 8K@60Hz/4K@120Hz)
I/O Ports (Internal)
PCIe ×16 slot (PCIe 4.0 ×4)
Button/Hole
1× Power Button (with LED)
1× BIOS Reset Hole
Pre-installed OS
OS Support
Windows 11 Pro
Windows 11 24H2 Pro / Home
Power
AC INPUT
(100-240V ~6A 50-60Hz, Internel-DC 12V/26.6A, 320W MAX)
VESA Mount & Dimensions
100-178.5mm
222.1 × 206.3 × 77.1 mm
Weight
2.8 kg
