SPECIFICATIONS
Pedal Body Material
Aerospace-grade aluminum alloy
Heel Plate Material
3K twill carbon fiber
Base Material
High-strength steel
Load Cell Sensor Range
0–200kg
Brake Sensor
Load cell sensor and angle sensor
Angle Sensor Resolution
15-bit (32768 PPR)
Brake Pedal Feel
115 standard adjustments, 1764 optional configurations
Throttle Adjustment
Two spring options with infinite adjustment
Clutch Adjustment
Two spring options with infinite adjustment
Brake Travel Adjustment
15–20°
Throttle Travel Adjustment
15–23°
Clutch Travel Adjustment
15–25°
Pedal Angle Adjustment
0–15°
Pedal Face Height Adjustment
Up to 30mm
Footrest Adjustment
Up to 30mm
Pedal Curve Adjustment
Adjustable
Real-time Pedal Output Display
Adjustable
Pedal Pressure Engagement Point
Adjustable
Pedal Surface
Biomimetic curved
Inverted Mounting Kit
Optional
