PENTING . IMPORTANT . 注意
KEPADA PELANGGAN YANG DIHORMATI,
SEBELUM MEMBUKA BUNGKUSAN SILA BUAT RAKAMAN VIDEO
BAGI TUJUAN TUNTUTAN KEROSAKAN DAN KEHILANGAN
SEBARANG TUNTUTAN TANPA RAKAMAN TIDAK AKAN DILAYAN.
SEGALA KERJASAMA AMATLAH DIHARGAI
DEAR VALUED CUSTOMER,
BEFORE UNBOXING THE PACKAGE PLEASE MAKE A
VIDEO RECORDING FOR FAULTY AND DAMAGE CLAIM PURPOSES
尊贵的顾客，请在打开包裹之前录制一段视频，
以确保产品损坏的情况有证据。未附带录制视频的索赔将无法受理。
谢谢您的合作
SPECIFICATION
***********************************************
DD R3
Platform
For XBOX Series X|S, XBOX ONE, AND PC
Drive Type
Direct Drive
Max Wheel Rotation
Limitless
Housing Material
Aviation Aluminum Alloy
Color
Black
Peak Torque
3.9 Nm
Rated Power
72W
Input Voltage
110V~220V AC —>12V DC
Encoder Resolution
15 bits
USB Refresh Rate
1000Hz
APP Functionality
Supported
Quick Release
Supported
Connection Ports
Power, DC Input, Pedal, USB, Dash
Accessories
Manual and Warranty Card, Power Supply, Data Cable, Toolkit
Mounting Method
4 holes on the bottom
Table Clamp
Included
Online Firmware Upgrade
Supported
***********************************************
ES Steering Wheel for Xbox
Grips
ISF PU
Face Plate Material
Aluminum Alloy
Shifter Paddle Material
Aluminum Alloy
Size
280mm
Buttons
22
RPM LED Light
10 High Brightness LED RGB Beads
Intelligent Telemetry
Supported
Fully Adjustable RPM LEDS through MOZA Pit House
Supported
Release Method
MOZA Quick Release
***********************************************
SR-P Lite Pedals
Material
High-strength Steel
Plate Material
High-strength Steel
Color
Black
Throttle Sensor
Hall Sensor
Pedal Spacing
Adjustable
Pedal Plate Height
Adjustable
Pedal Input Adjustment
Supported
Pedal Input Reversal
Supported
Pedal Output Curve Adjustment
Supported
Anti-Slip Pad
Included
***********************************************
WHAT'S INBOX
● R3 DD Wheelbase x1
● ES Steering Wheel for Xbox x1
● SR-P Lite Pedals (No Clutch) x1
● Table Clamp
● 15 Degree Desktop Mounting Clip
● Power Adapter
● Power Cord
● USB Cable
● M4*10 Countersunk Screws x12
● USB A to B Cable
● M8*12 Pan Head Hex Screws x3
● M6*20 Hex Head Bolts x2
● M8 Nuts x3
● M6x12 Hex Head Cap Screw x4
● Spacers x2
● 2.5mm Allen Wrench x1
● 7mm Open-end Spanner x1
● 5mm Allen Wrench x1
**(2 Years Warranty for Wheelbase, 1 Year Warranty for Steering Wheel & Pedal)
*Change Of Mind/I Do Not Want The Product Anymore/Return Policy Does NOT Apply For Order(s) & Product(s) Which Has Been Used, Unboxed, Unsealed, Tampered, Not Returned Along Full Documentation/Tax Invoice & Original Retail Box With Shipping Packing
