Specifications General
Model No. PH-ES620PC_BK02
Case Dimensions 240 x 580 x 560 mm | 9.45 x 22.83 x 22.05 in
Form Factor Full Tower
Mainboard Support XL-ATX | SSI-EEB | E-ATX | ATX | Micro-ATX | Mini-ITX
Materials Steel chassis
Side Window No
PCI Slots 11
Vertical GPU Support 3-slots
Riser Cable sold separately
Internal 2.5″ Bay
11
Internal 3.5″ Bay
10 | 4 Included
+ 3x 2.5″ SSD
Front I/O
1x USB-C GEN 2
4x USB 3.0
Microphone | Headphone Combo
Reset Button
Power Button
Fans
Total Fans
120 mm | 140 mm
15x | 6x
Top
3x | 3x
Front
4x | 3x
Side
4x | –
Bracket
3x | –
Rear
1x | –
Radiators
Top
Max. 360 | –
Front
Max. 480 | 420
Side
Max. 480 | –
Rear
120 | –
Bracket
– | –
Clearance
CPU Cooler
Height
195 mm | 7.67 in
GPU
Length
503 mm | 19.95 in
Mainboard
Height x Width
Max. 375 x 330 mm | 14.76 x 12.99 in
Top Radiator
Length x Width
120 x 475 mm (Max. 55 mm mainboard height) | 4.72 x 18.70 in (Max. 2.16″ mainboard height)
Front Radiator
Length x Width
142 x 475 mm | 5.59 x 18.70 in
Side Radiator
Length x Width x Height
134 x 525 x 35 mm | 5.27 x 20.66 x 1.37 in
Extra
Net Weight
13.19 kg | 29.08 lbs
Gross Weight
15.47 kg | 34.11 lbs
Warranty
5 Years limited
Scope of Delivery
1x Enthoo Pro II Server Edition chassis
1x Left side bracket
3x SSD bracket
4x HDD bracket
Accessory Box
6x Zip ties
1x GPU support bracket
1x Server PSU bracket
1x Phanteks case badge
Screws
18x Mainboard | SSD screws
5x Power supply screws
12x Fan screws
1x Motherboard stand-off
2x HDD cage screws
