● 80 PLUS Gold efficiency certification
● Equipped with Gen5 12V-2x6 PCIe connector, meeting Intel ATX 3.0 specification standard
● Latest PCIe Gen 5 standard to support up to 2X power excursion
● 24/7 continuous power output with 50℃operating temperature
● Silent running 120mm fan with advanced semi-fanless operation
● Compact design with a 140mm depth for easy integration
Product Specifications
Product No.
SST-DA750R-GMA-WWW (White)
SST-DA750R-GMA (Black)
Model (safety certification)
SST-AX0750MCGD-C
Color
White (lead-free paint)
Black (lead-free paint)
Max. DC Output
750W
Power density
415W/L
Load Range
Output+3.3V+5V+12V+5VSB-12VMax.(Amps)20A20A62.5A3A0.3AMin.(Amps)0A0A0A0A0ARange (%)±3%±3%+5%-7%±5%±8%Line Reg.(%)±1%±1%±1%±1%±1%Ripple(mVp-p)40mV40mV80mV40mV80mV
Combined +3.3V & +5V
100W
Combined +12V
750W
Input Voltage
90 ~ 264 Vrms
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC (PF>0.9 at full load)
Efficiency
≥87% & <89%
MTBF
100,000 hours
Operating temperature
0°C ~ 50°C
Protection
Over Current Protection
Over Power Protection
Over Voltage Protection
Short Circuit Protection
Over Temperature Protection
Under Voltage Protection
Connectors
1 x 24 / 20-Pin motherboard connector
2 x 8 / 4-Pin EPS / ATX 12V connector
4 x 8 / 6-Pin PCIe connectors
1 x 12V-2x6 connector
8 x SATA connectors
4 x 4-Pin Peripheral connector
※ DA750R-GMA/DA750R-GMA-WWW are not compatible with PP05-E and PP06 cables.
Cooling System
Silent 120mm fan
Noise Level
0 dBA minimum
Certification
80 PLUS Gold
Form factor
ATX (PS2)
Dimension
150mm (W) × 86mm (H) × 140mm (D)
5.91" (W) x 3.39" (H) x 5.51" (D)
Weight
2.08kg
